| Items | Unit | Machine Models | ||||
|---|---|---|---|---|---|---|
| MAX2-5L | MAX3-5L | MAX4-5L | MAX6-5L | |||
| Bottle Spec. | Cavity Qty | CAV | 2 | 3 | 4 | 6 |
| Max. Bottle Volume | L | 5 | 5 | 5 | 5 | |
| Max. Neck Size | MM | 55 | 55 | 55 | 55 | |
| Max. Bottle Diameter | MM | 180 | 180 | 180 | 180 | |
| Max. Bottle Height | MM | 350 | 350 | 350 | 350 | |
| Theoretical Output | BPH | 2200 | 3400 | 4400 | 6000 | |
| Molding Spec. | Pitch in Oven | MM | 63.5 | 63.5 | 63.5 | 63.5 |
| Bottle Pitch | MM | 200 | 200 | 200 | 200 | |
| Power | Heating Power | KW | 60 | 96 | 124 | 148 |
| Rated Total Power | KW | 75 | 110 | 145 | 162 | |
| Consuming Power | KW | 48 | 60 | 72 | 85 | |
| Compressed Air | Action Pressure | BAR | 7 | 7 | 7 | 7 |
| Low Pressure Consumption | 1.5 | 1.5 | 1.5 | 1.5 | ||
| Blowing Pressure | BAR | 25-35 | 25-35 | 25-35 | 25-35 | |
| High Pressure Consumption | 8 | 9 | 12 | 16 | ||
| Cooling Water | Cooling Water Pressure | BAR | 5 | 5 | 5 | 5 |
| Cooling Water Temperature | C | 12 | 12 | 12 | 12 | |
| Chiller Power | HP | 8 | 8 | 10 | 15 | |
| Machine Spec. | Machine Size | M | 5.2*2.0*2.4 | 6.3*2.0*2.4 | 8.8*2.0*2.4 | 9.8*2.0*2.4 |
| Machine Weight | KG | 6800 | 8200 | 9800 | 11500 | |
