| Items | Unit | Machine Models | |||||||
|---|---|---|---|---|---|---|---|---|---|
| MS-3L | MS-3L-TWIN | MS4-1.5L | MS1-5L | MS2-5L | MS1-10L | MS-20L | |||
| Molding | Cavity Qty. | cav. | 2 | 4 | 4 | 1 | 2 | 1 | 1 |
| Bottles | Max. Bottle Volume | 3L | 1.5L | 5L | 5L | 10L | 20L | ||
| Neck Size | mm | 18-38 | 18-38 | 18-95 | 18-95 | 38-120 | 38-120 | ||
| Max. Bottle Diameter | mm | 140 | 105 | 190 | 190 | 200 | 300 | ||
| Max. Bottle Height | mm | 360 | 350 | 350 | 350 | 420 | 550 | ||
| Theoritical Output | BPH | 700 - 1.000 | 1.400 - 2.000 | 1.400 - 1.800 | 300 - 400 | 500 - 700 | 300 - 400 | 60 - 240 | |
| Power | Rated Power | KW | 22 | 30 | 25 | 25 | 30 | 30 | 50 |
| Air Supply | Blowing Pressure | Mpa | 2.5 - 4.0 | 2.5 - 4.0 | 2.5 - 4.0 | 2.5 - 4.0 | 2.5 - 4.0 | 2.5 - 4.0 | |
| Motion Pressure | Mpa | 0.8 - 1.2 | 0.8 - 1.2 | 0.8 - 1.2 | 0.8 - 1.2 | 0.8 - 1.2 | 0.8 - 1.2 | ||
| Machine Size | Blower Size | mm | 1.6 x 0.62 x 1.6 | 1.6 x 0.62 x 0.6 | 1.6 x 0.88 x 2.3 | 1.95 x 0.65 x 1.75 | 1.96 x 0.8 x 2.3 | 1.9 x 0.7 x 1.7 | 2.5 x 0.8 x 1.9 |
| Oven Size | mm | 1.7 x 0.58 x 1.36 | 2.2 x 0.6 x 1.35 | 1.65 x 0.6 x 1.22 | 1.7 x 0.6 x 1.35 | 2.2 x 0.6 x 1.35 | 2.2 x 0.6 x 1.35 | 2.6 x 0.75 x 1.58 | |
| Machine Weight | KGS | 1,000 | 1,200 | 1,200 | 1,000 | 1,200 | 1,100 | 1,450 | |
