TURBO Series Full Servo High-speed Models
- Features
- Full Servo control 4 main structures: Feeding, Shifting, Clamping, Stretching.
- Advanced PTO System (Pulse/Train/Output Servo Positioning Module) work on high speed positioning, with higher speed, higher noise immunity and precise positioning.
- High speed, stable, low noise, 500ml production 6-cavity model capacity 10,000BPH, 9-cavity model capacity 13,000BPH.
| Items | Unit | Machine Models | |||||
|---|---|---|---|---|---|---|---|
| TURBO2-2L | TURBO4-2L | TURBO6-0.7L | TURBO6-2L | TURBO9-0.7L | |||
| Molding | Cavity Pitch | mm | 120 | 114.3 | 76.2 | 114.3 | 76.2 |
| Cavity Qty. | cav. | 2 | 4 | 6 | 6 | 9 | |
| Bottles | Max. Bottle Volume | 2L | 2L | 700ml | 2L | 700ml | |
| Neck Size | mm | 18-38 | 18-38 | 18-38 | 18-38 | 18-38 | |
| Max. Bottle Diameter | mm | 105 | 105 | 70 | 105 | 70 | |
| Max. Bottle Height | mm | 330 | 330 | 260 | 330 | 260 | |
| Theoritical Output | BPH | 2.200 - 2.800 | 4.500 - 5.500 | 9.000 - 10.000 | 6.500 - 8.000 | 12.500 - 13.000 | |
| Power | Rated Power | KW | 60 | 80 | 80 | 140 | 145 |
| Consuming Power | KW | 40 | 50 | 45 | 70 | 76 | |
| Air Supply | Blowing Pressure | Mpa | 2.5 - 4.0 | 2.5 - 4.0 | 2.5 - 4.0 | 2.5 - 4.0 | 2.5 - 4.0 |
| Motion Pressure | Mpa | 0.8 - 1.2 | 0.8 - 1.2 | 0.8 - 1.2 | 0.8 - 1.2 | 0.8 - 1.2 | |
| Machine Size | Main Machine Size | M | 2.92 x 2.0 x 2.4 | 3.65 x 2.15 x 2.45 | 4.3 x 2.15 x 2.25 | 5.85 x 2.2 x 2.3 | 5.85 x 2.2 x 2.3 |
| Machine Weight | KGS | 2,850 | 5,000 | 5,500 | 8,000 | 8,000 | |
